Main features
- Compact design
- Rugged housing
- Protection IP 65
- Diverse mounting positions
About
Technical Data
| Product code | 404/414 |
|---|---|
| Name | I/IS |
| Designation | Industat |
| Product category | Thermostats |
| Applications | RailwaysMachine tools |
| Measuring range | -30°C ... +40°C to +70°C ... +350°C |
| Repeatability | ± 0.5 % FS typ. |
| Designation of application | Industrial thermostat with remote sensor |
| Approval / conformity | EN60730-1/ EN60730-2-9: Type 2.B.H |
| Output signal | Floating change-over contact |
| Ambient temperature | Range ≤ +45°C: -30°C ... +50°C Range +45°C ... +250°C: -30°C ... +70°C Range > + 250°C: -10°C ... +70°C (Important: Temperature at sensor may not exceed maximum sensor temperature) |
